Amosolar Co.,Ltd ---- Professional Solar Manufacturer
Longi 182 Solar Panel Mono Half Cell 440W 445W 450W A Grade Solar Panel
Products
Home / SOLAR PANEL / Tier 1 PV Module /

Longi 182 Solar Panel Mono Half Cell 440W 445W 450W A Grade Solar Panel

Tier 1 Solar Panel Original
Tier 1 Solar Panel Original
Tier 1 Solar Panel Original
Tier 1 Solar Panel Original

Longi 182 Solar Panel Mono Half Cell 440W 445W 450W A Grade Solar Panel

LR5-54HTB 440-450M





Cell Arrangement :      108 (6 X 18)

Junction Box :            IP68, 3 diodes


Weight:                     20.8KG


Cable Length :           +400,-200mm/ ±1400mm


Cable  Size :               4 mm2 (IEC)


PV Size:                      1722×1134×30mm


Packaging:                 36 pcs / pallet   936pcs / 40HQ container









Electrical Performance Parameters (STC Test)



Model LR5-54HTB-440M LR5-54HTB-445M LR5-54HTB-450M
Rated Maximum Power at STC 440W 445W 450W
Open Circuit Voltage (Voc) 39.83 40.03 40.23
Maximum Power Voltage (Vmp) 33.56 33.76 33.96
Short Circuit Current (Isc) 14.15 14.23 14.31
Maximum Power Current (Imp) 13.12 13.19 13.27
PV Module Efficiency (%) 22.50 22.80 23.00
Standard Inradiance 1000w/m² , Cell Temperature 25 ℃ , Air Mass 1.5
